Integra Line 660 EB
360° Panorama:
Technical data
| Basic vehicle | Fiat Ducato 16" / 3,5 t / Fiat CCS low-slung frame |
|---|---|
| Engine models | 2.3 ltr. 103 kW (140 HP) |
| Engine models (optional) | 118 kW (160 HP), 130 kW (180 HP) |
| Total techn. perm. Weight when laden (kg) | 3500 / 4250 / 4400 kg |
| Weight in ready-to-drive state* (kg)( 1 ) | 3015 kg |
| Trailer weight* (braked) (kg)( 2 ) | 2000 / 1800 / 1750 kg |
| Double floor height (mm) | 110 |
| Wheelbase (mm) | 4035 |
| Tyres | 225/75 R16C |
| Total length (mm) | 6990 |
| Total width (mm) | 2322 |
| Total height (mm) | 2880 |
| Interior width (mm) | 2174 |
| Standing height (mm) | 1975 |
| Front side seating group (mm) | 1150 x 1050 |
| Bed conversion of the seating group (mm)( 3 ) | - |
| Rear bed (mm) | 1930 x 8001930 x 800 |
| Alcove bed / Lift-up bed (mm) | 1850 x 1500 |
| Sleeping areas | 4 |
| Extension to X sleeping areas | |
| Permissible number of people with 3-point seatbelts total* | 4 |
| Seat extension to X persons (Option)( 4 ) | |
| Wall thickness of wall (mm) | 30 |
| Wall thickness of roof (mm) | 30 |
| Wall thickness of floor (mm) | 38 |
| Battery capacity (Ah) | 1 x 80 Ah Gel |
| Fresh water tank (ltr.)( 5 ) | 140 ltr. |
| Water volume in drive position (ltr.) | 100 ltr. |
(1)Weight in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard equipment as per manufacturer specifications, 90 % of the fill capacity for fuel, 100 % water in drive position and gas (11 kg gas cylinder made of aluminium), without optional equipment
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: only with 2-point lap belts facing away from the direction of travel and 40H chassis | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Engine
| serial/optional | |
|---|---|
| 160 HP FIAT engine (surcharge on 140 HP engine) | optional |
| 180 HP FIAT engine (surcharge on 140 HP engine) | optional |
| 180 HP FIAT engine (surcharge on 160 HP engine) | optional |
| 140 HP FIAT engine | serial |
Other options
| serial/optional | |
|---|---|
| Automatic gearbox | optional |
| Spare wheel (depending on model) | optional |
| Tire pressure sensors | optional |
| Fuel tank 90 l | optional |
| Right-hand drive | optional |
| Dashboard with chrom rings | optional |
Wheels
| serial/optional | |
|---|---|
| Alu wheels 16 inch | optional |
Total mass
| serial/optional | |
|---|---|
| Chassis Maxi instead of 35 L / 4,25t (additional charge) | optional |
| Chassis Maxi instead of 3,5t / 4,4t (additional charge) | optional |
| Increase of total mass when loaded to 3,65 t | optional |
| Off-load to 3,5t (depending on model) | optional |
| Reinforced front suspensions | optional |
Exterior
| serial/optional | |
|---|---|
| Living area door with central locking system | optional |
| Rear corner steadies | optional |
| Trailer Coupling | optional |
| Outside shower (cold/hot) driver side | optional |
| Elect. roof fan | optional |
| Roof canopy HEKI | optional |
| Storage trapdoor: add. garage trap (left) | serial |
Interior
| serial/optional | |
|---|---|
| Winter wiper park position | optional |
| Insulating mat for cabin floor | optional |
| Insulating double glazing in the side windows | optional |
| Floorheating for cabin | optional |
| Cabin blinds | serial |
| Elec. front pleading (incomp w. elec. roller blind) | optional |
| Fly screen for body door | optional |
| Drop-Down bed: electronically height adjustable | optional |
| Table with chrome table foot and edge trim | optional |
| Overhead cupboard instead drop-down bed with front pleading | optional |
Equipment packages
| serial/optional | |
|---|---|
| Exclusive Designer Package Integra Line (LED headlights with LED indicator and fog lights, chrom elements front and rear) | optional |
| Comfort Package Integra Line (Driver’s cab air manual conditioning system, cruise control, lordosis support with height adjustment for pilot’s seat, moniceiver with rear- view camera, carpet in the driver’s cab) | optional |
| Prestige Package Integra Line (Steering wheel and gearshift knob in leather finish, steering wheel with control elements, automatic climate control, moniceiver with navigation & rear-view camera system (twin-eye)) | optional |
| Prestige Package Integra Line (surcharge on comfort package) (Steering wheel and gearshift knob in leather finish, steering wheel with control elements, automatic climate control, moniceiver with navigation & rear-view camera system (twin-eye)) | optional |
| Arctic Pack Integra Line Truma 650-695 (Windscreen wipersystem with winter parking position, heat-insulating double glazing in the side windows, Elec. front pleading, heat exchanger for Truma heating, Combi 6 Eheating, Truma duo control with remote display, de-icer and crash sensor) | optional |
| Arctic Package Integra Line ALDE (Windscreen wiper system with winter parking position, heat-insulating double glazing in the side windows, Elec. front pleading, heat exchanger for Alde heating, Truma duo control with remote display, de-icer and crash sensor, floor heating in driver’s cab) | optional |
| Energy Plus Package (Second Lithium battery, lithium- battery with charge booster) | optional |
| Plug in Package (outside shower (cold/warm) driver side, Gas socket - co-driver side, Multifunctional socket (230V, 12V and SAT sockets), Toilet ventilation (SOG system)) | optional |
| Mondial Package Integra Line with electr. roof fan (Comfort Package Integra Line, Touring Package Integra Line, 16 inch aluminium rings, dashboard with chrome rings, hydraulically height-adjustable central bed on QB variants) | optional |
| Mondial Plus Package IL 650-695 Alde (Prestige Package, Arctic Package Integra Line ALDE, Plug-in Package, 160 HP Fiat engine, Maxi-chassis instead of 3,5t/4,4t, solar panels (2 x 100 watt), awning) | optional |
| Mondial Plus Package IL 650-695 Truma (Prestige Package, Arctic Package Integra Line 650-695, Plug-in Package, 160HP Fiat engine, Maxi-chassis instead of 3,5t/4,4t, solar panels (2 x 100 watt), awning) | optional |
Multimedia
| serial/optional | |
|---|---|
| Loudspeaker (2) in the living space | optional |
| SAT aerial - fully automatic (w. TV-precabling) | optional |
| Flat screen holder behind side bench | optional |
| TFT screen 32'' front | optional |
| Flat-screen pull-out front | optional |
Additional optional extras
| serial/optional | |
|---|---|
| Bedspread EB | optional |
| Cabin seats with living area fabric | serial |
| Decoration Vila | optional |
| Decoration Lento | optional |
| Decoration Mara | optional |
| Decoration Maka | optional |
| Decoration Lasca | optional |
| Carpet in living area | optional |
Bicycle carrier
| serial/optional | |
|---|---|
| Bicycle rack - expanding kit from 2 to 4 bikes (max 60kg) | optional |
| Bicycle rack for 2 bikes (max 30 kg) | optional |
| Bicycle rack for 2 E-bikes, lowerable | optional |
Technical services
| serial/optional | |
|---|---|
| Roof air conditioner 230 Volt (not in combination with electric roof fan) | optional |
| Solar panels (2 x 100 watt) | optional |
| Multifunctional socket (230V, 12V and SAT sockets) | optional |
| Heat exchanger | optional |
| Heat exchanger for Alde | optional |
| Alarm system for doors and garage folds | optional |
| Lithium battery with jump starter | optional |
| Second Lithium battery | optional |
| Second 80 Ah Gel battery | optional |
| Precabling for solar panels | optional |
| Gas socket - co-driver side | optional |
| Duo Control CS with EisEx | optional |
| Toilet ventilation (SOG system) | optional |
| Used water tank insulated and heated | serial |
| Background lighting | serial |
Sunblinds
| serial/optional | |
|---|---|
| Awning 4,5 m - mechanical | optional |
Fabrics
| serial/optional | |
|---|---|
| Upholstery Milano | optional |
| Upholstery Dara | optional |
| Upholstery Pisa | optional |
| Upholstery Leather beige | optional |
| Upholstery Leather Grey | optional |
| Upholstery Leather Mocca | optional |
| Upholstery Como | optional |
Furniture
| serial/optional | |
|---|---|
| Furniture Design Chalet | serial |
| Furniture Design Navarra | optional |
Heating
| serial/optional | |
|---|---|
| Warm-air heater | serial |
| Warm water heating system ALDE | optional |
| Heating system Combi 6 EH (surcharge Combi 4) | optional |
Kitchen
| serial/optional | |
|---|---|
| Extractor hood | optional |
| Large fridge | serial |
Additional products
| serial/optional | |
|---|---|
| 1 year extented warranty until 4,5t | optional |
| 2 years extented warranty until 4,5t | optional |
| 3 years extented warranty until 4,5t | optional |
