Integra Line 730 EF

Model range Integra Line

IL 730 EF

Length: 7,58 m
Sleeping areas: 4

Integra Line 730 EF

Panorama:

Please click the button below to load the content from Matterport Panorama.

With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren

Load content

Technical data

Basic vehicle Fiat Ducato
Engine models 2,2 ltr.
Engine models (optional) 2,2 ltr.
Double floor height (mm) 110
Wheelbase (mm) 4035
Tyres 225/75 R16C
Total techn. perm. Weight when laden (kg)( 1 ) 3500 / 4250 / 4400 kg
Weight in ready-to-drive state* (kg)( 2 ) 3204 (3044 - 3364)
Trailer weight* (braked) (kg) 2000 / 1800 / 1750 kg
Maximum dimensions for packages and optional extras( 4 ) 740,90
Total length (mm) 7577
Total width (mm) 2322
Total height (mm) 2880
Interior width (mm) 2174
Standing height (mm) 1975
Front side seating group (mm) 1000
Bed conversion of the seating group (mm)( 3 ) 2000 x 1000
Rear bed (mm) 2000 x 7501970 x 750
Coachbuild bed / Lift-up bed (mm) 1930 x 1500
Extension to X sleeping areas 6
Permissible number of people with 3-point seatbelts total*( 3 ) 3
Seat extension to X persons 4 ab 3650 kg Gesamtmasse
Wall thickness of wall (mm) 30
Wall thickness of roof (mm) 30
Wall thickness of floor (mm) 38
Fresh water tank (l)( 5 ) 138 ltr.
Waste water tank (l)( 5 ) 10 ltr.
Battery capacity (Ah) 1 x 80 Ah Gel
Water volume in drive position (l) 100 ltr.
(1)The technically permissible overall weight in a laden state refers to the overall weight defined by the manufacturer that the vehicle may not exceed when in drive mode. (2)The weight in ready-to-drive state refers to the weight of the vehicle (with standard features according to the manufacturer's specifications) with its fuel tank filled to at least 90% of capacity and includes the weight of the driver (which is calculated at a nominal value of 75 kg), the weight of the fuel and fluids, the weight of the superstructure and the driver's cab, and the weight of the towing hitch and the tyre repair kit (to the extent these are present). This represents a calculated value that is subject to legally permissible fluctuations of up to ± 5% (see additional text in brackets). Since these legally permissible fluctuations impact the vehicle's payload and therefore also the weights of the packages and special equipment that can be ordered, the occurrence of such fluctuations must be factored into the configuration process and the choice of packages and special equipment. (3)The weight of the passengers is calculated at a nominal 75 kg per seat, whereas the weight of the driver, which was already taken into account in the weight in the ready-to-drive state, must be deducted. In the case of a vehicle with four belt-restrained seats, the weight of the passengers is therefore 225 kg (3 x 75 kg). (4)The maximum weights for packages and special equipment represent a value calculated for each floor plan with which we have restricted the weights for the packages and special equipment that can be ordered from the factory. This is intended to ensure that the legally prescribed minimum payload is complied with after the vehicle is shipped from the factory. If the configuration process leads to the upper limit for this defined by the manufacturer being exceeded as a result of the choice of packages and special equipment, you can only continue with the configuration process if you de-select packages, special equipment or belt-restrained seats or choose to in-crease the vehicle's load capacity. Otherwise, you will not be able to configure or ordering the configured vehicle. Please note that the calculation of the maximum weights for packages and special equipment also takes into account the special equipment features of the selected country variation / the selected special model. The selected vehicle is currently shown in the country variation United Kingdom. Important information regarding vehicle weights can be found here (5)Please note that the capacity of the fresh water tank is significantly reduced in the drive position. If the payload of the individual vehicle is sufficient, it can be filled to its full capacity.

Equipment

Engine

serial/optional
Fiat 180 HP motor (surcharge compared to 140 HP) serial

Other options

serial/optional
Fiat automatic transmission (140 HP & LD) optional
Fiat automatic transmission (180HP & HD) serial
Reinforced front axle springs optional
Fuel tank, 90 litre serial

Total mass

serial/optional
Maxi chassis 4.25t optional
Maxi chassis 4.4t serial
Increase of total mass to 3.65t optional
Reduction of total mass to 3.5 t optional

Exterior

serial/optional
Superstructure door with central locking serial
Rear comfort supports optional
Trailer coupling optional
Roof-mounted air-conditioning system 230 Volt optional
Roof-mounted air-conditioning system 230 Volt (surch. Mond.) optional
Electric roof fan serial
Tilting roof hood (Heki) serial
Mesh screen for body door serial
Garage door service flap serial

Equipment packages

serial/optional
Exclusive design package optional
Mondial package Integra Line (electric parking brake, Traction Plus incl. Hill-Descent-Control, steering wheel controls, 16 aluminium rims, Steering wheel and gearshift knob in leather, Dashboard panel in Techno-Trim, moniceiver (Xzent) with rear-view camera, Comfort seats Integra Line with lordosis support & height adj., Manual blackout system, tilting roof hood (Heki), superstructure door with central locking, electric roof fan, mesh screen for body door, pre-cabling for solar power system) optional
Mondial-Plus Package Integra Line (automatic transmission, Fiat 180 HP motor, Heavy Duty, maxi chassis 4.4t, 90 litre fuel tank, automatic air conditioning, inductive charging station, Digital dashboard 7, naviceiver with rear-view camera, carpet in the driver’s cab, multi-function socket, external shower (hot/cold), external gas socket, insulating double glazing, electric front pleated blinds, Lithium battery) optional

Multimedia

serial/optional
Loudspeakers (2) in superstr. optional
Flat screen wall bracket in front area optional
Flat screen wall bracket in rear area optional

Interior

serial/optional
Comfort seat serial
Driver cab floor insulating mat optional
Insulating double glazing serial
Driver cab floor heating (heated floor mat / Alde heating) optional
Cab floormat serial
Driver's cab dimming system serial
Electric front pleading serial
Protective cover in superstructure upholstery for cab seats serial
Additional bed for 2 people (conversion of seating group) optional
Electrically adjustable lift-up bed for 2 people optional
Manually adjustable lift-up bed serial
Storage cabinets instead of lift-up bed optional
Background lighting serial

Additional optional extras

serial/optional
EB bedspread optional
Maka décor serial
Lasca décor optional
Rana décor optional
Evono décor optional

Bicycle carrier

serial/optional
Bike carrier extension kit 4-way optional
Bike carrier for 2 bikes optional

Sunblinds

serial/optional
5 m canopy optional

Technical services

serial/optional
Multi-function socket serial
External shower (cold/warm) serial
Lithium battery (1x) serial
Lithium batteries (2x) optional
2nd gel battery - 80 Ah optional
Pre-cabling for solar power system serial
Autonomous E-bike charger optional
External gas socket serial
Duo Control CS with ice-ex optional

Fabrics

serial/optional
Milano upholstery fabric optional
Upholstery "Glendale" optional
Dara upholstery fabric optional
Bergamo upholstery fabric optional
Pisa upholstery fabric optional
Leather beige upholstery fabric optional
Leather grey upholstery fabric optional
Como upholstery fabric serial

Furniture

serial/optional
Chalet furniture décor serial

Kitchen

serial/optional
Extractor hood optional
Oven optional
Large refrigerator serial

Versicherungsprodukte

serial/optional
2 year follow-on guarantee < 4.5t optional
3 year follow-on guarantee < 4.5t optional

Additional products

serial/optional
Reduction of travel seats by 1 optional
Reduct. of travel seats by 2 optional
Reduction of travel seats by 3 optional
Reduction of travel seats by 4 optional
