Integra 760 EF
360° Panorama:
Please click the button below to load the content from Matterport Panorama.
With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren
Technical data
| Basic vehicle | Fiat Ducato / AL-KO |
|---|---|
| Engine models | 2,2 ltr. |
| Engine models (optional) | 2,2 ltr. |
| Double floor height (mm) | 195 |
| Wheelbase (mm) | 4450 ( 4035 + 800 ) |
| Tyres | 225/75 R16C |
| Total techn. perm. Weight when laden (kg) | 4500 kg (5500 kg) |
| Weight in ready-to-drive state* (kg)( 1 ) | 3625 kg (3760 kg) |
| Trailer weight* (braked) (kg)( 2 ) | 1890 kg (1600 kg) |
| Total length (mm) | 7890 |
| Total width (mm) | 2322 |
| Total height (mm) | 2920 |
| Interior width (mm) | 2174 |
| Standing height (mm) | 1975 |
| Front side seating group (mm) | 1150 |
| Bed conversion of the seating group (mm)( 3 ) | 1900 x 1000 |
| Rear bed (mm) | 1950 x 8002000 x 800 |
| Coachbuild bed / Lift-up bed (mm) | 1930 x 1500 |
| Extension to X sleeping areas | 6 |
| Permissible number of people with 3-point seatbelts total* | 4 |
| Seat extension to X persons( 4 ) | 4 |
| Wall thickness of wall (mm) | 30 |
| Wall thickness of roof (mm) | 30 |
| Wall thickness of floor (mm) | 38 |
| Fresh water tank (l)( 5 ) | 140 ltr. |
| Battery capacity (Ah) | 1 x 80 AH Gel |
| Water volume in drive position (l) | 100 ltr. |
(1)Dimensions in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard features according to the manufacturer specifications, 90% of the fill capacity for fuel, 75 kg (weight of the driver), water in drive position and gas (11 kg gas cylinder made of aluminium), without special features
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: Only with seat belts facing away from the direction of travel and 40 H chassis | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Other options
| serial/optional | |
|---|---|
| Fiat automatic transmission | optional |
| ull air suspension 3-axle model, 5.5 t permissible total w. | optional |
| Reinforced front axle springs | serial |
| 2-axle full air suspension | optional |
| 3-axle instead of 2-axle | optional |
| Fuel tank, 90 litre | serial |
| Heatable windscreen | optional |
| Heavy Duty | serial |
| Carbon external décor | serial |
Exterior
| serial/optional | |
|---|---|
| Superstructure door with central locking | serial |
| Windscreen wiper system with winter parking position | optional |
| Rear comfort supports | optional |
| ALKO support system | optional |
| Trailer coupling | optional |
| Roof-mounted air-conditioning system 230 Volt | optional |
| External shower (cold/warm) | optional |
| Window in toilet room | serial |
| Electric roof fan | serial |
| Tilting roof hood (Heki) | serial |
| Garage door service flap | serial |
Equipment packages
| serial/optional | |
|---|---|
| Exclusive design package | serial |
| Luminary Package Integra 760 2-axle (Comfort seats with seat htg, lordosis support & height adj., Naviceiver with twin eye rear-view camera, steering wheel controls, Pre-cabling for solar power system, carpet in the driver’s cab, Fiat automatic transmission, 16 aluminium rims, Carbon external décor, chrome elements at the front & rear, LED turning light, LED fog lights, Flat screen wall bracket in front area, Flat screen wall bracket in rear area, Organisation system for rear garage, Sound system, automatic air conditioning, leather steering wheel and gearshift knob, inductive charging station, heat exchanger) | optional |
| Luminary Pack. Integra 760 3 axle | optional |
| Luminary-Plus Package Integra 760 2-axle (Multi-function socket, External shower (cold/warm), External gas socket, Windscreen wiper system with winter parking position, Insulating double glazing, Lithium battery (1x), 5.5 m mechanical canopy, Heatable windscreen, Underfloor camera for electrical tank emptying) | optional |
| Luminary-Plus Package Integra 760 3-axle (Multi-function socket, External shower (cold/warm), External gas socket, Windscreen wiper system with winter parking position, Insulating double glazing, Lithium battery (1x), 5.5 m mechanical canopy, Heatable windscreen, Underfloor camera for electrical tank emptying) | optional |
Multimedia
| serial/optional | |
|---|---|
| Sound system | optional |
| Flat screen wall bracket in front area | optional |
| Flat screen wall bracket in rear area | optional |
Interior
| serial/optional | |
|---|---|
| Comfort seat | optional |
| Driver cab floor insulating mat | optional |
| Driver cab floor heating (heated floor mat / Alde heating) | optional |
| Electric front pleading | serial |
| Mesh screen for cabin door | serial |
| Driver cab seats in superstructure upholstery | serial |
| Additional bed for 2 people (conversion of seating group) | optional |
| Electrically adjustable lift-up bed | serial |
| Carpeted floor in superstructure | serial |
| Table with chrome-plated table pedestal | serial |
| Storage cabinets instead of lift-up bed | optional |
| Organisation system for rear garage | optional |
| Background lighting | serial |
Additional optional extras
| serial/optional | |
|---|---|
| Integra/Contura on EB bedspread | optional |
| Maka décor | serial |
| Lasca décor | optional |
| Rana décor | optional |
Bicycle carrier
| serial/optional | |
|---|---|
| Bicycle carrier for 2 bicycles or 2 E-bikes (up to 60 kg) | optional |
| Bike carrier extension kit 4-way | optional |
Sunblinds
| serial/optional | |
|---|---|
| 5.5 m canopy | optional |
Technical services
| serial/optional | |
|---|---|
| Multi-function socket | optional |
| Underfloor camera for electrical tank emptying | optional |
| Heat exchanger | optional |
| Lithium battery (1x) | optional |
| Lithium batteries (2x) | optional |
| 2nd gel battery - 80 Ah | optional |
| Pre-cabling for solar power system | optional |
| External gas socket | optional |
| Duo Control CS with ice-ex | serial |
Fabrics
| serial/optional | |
|---|---|
| Milano upholstery fabric | optional |
| Dara upholstery fabric | optional |
| Pisa upholstery fabric | optional |
| Leather beige upholstery fabric | optional |
| Leather grey upholstery fabric | optional |
| Como upholstery fabric | serial |
Furniture
| serial/optional | |
|---|---|
| Navarra furniture décor | serial |
Heating
| serial/optional | |
|---|---|
| Hot water heating - Alde | serial |
Kitchen
| serial/optional | |
|---|---|
| Extractor hood | serial |
| Oven | serial |
| Large refrigerator | serial |
Versicherungsprodukte
| serial/optional | |
|---|---|
| 1 year follow-on guarantee < 4.5t | optional |
| 2 year follow-on guarantee < 4.5t | optional |
| 3 year follow-on guarantee < 4.5t | optional |
Additional products
| serial/optional | |
|---|---|
| Reduction of travel seats by 1 | optional |
| Reduct. of travel seats by 2 | optional |
| Reduction of travel seats by 3 | optional |
| Reduction of travel seats by 4 | optional |
