Profila T 675 SB
Technical data
| Basic vehicle | Fiat Ducato |
|---|---|
| Engine models | 2,2 ltr. |
| Engine models (optional) | 2,2 ltr. |
| Double floor height (mm) | 110 |
| Wheelbase (mm) | 4035 |
| Tyres | 225/75 R16C |
| Total techn. perm. Weight when laden (kg) | 3500 / 4250 / 4400 kg |
| Weight in ready-to-drive state* (kg)( 1 ) | 2930 kg |
| Trailer weight* (braked) (kg)( 2 ) | 2000 / 1800 / 1750 kg |
| Total length (mm) | 6990 |
| Total width (mm) | 2322 |
| Total height (mm) | 2860 |
| Interior width (mm) | 2174 |
| Standing height (mm) | 1975 |
| Front side seating group (mm) | 1150 x 1050 |
| Bed conversion of the seating group (mm)( 3 ) | 2000 x 1240 |
| Rear bed (mm) | 1950 x 1370 |
| Coachbuild bed / Lift-up bed (mm) | - |
| Extension to X sleeping areas | 4 |
| Permissible number of people with 3-point seatbelts total* | 4 |
| Seat extension to X persons( 4 ) | 5(ab 3650 kg Gesamtmasse) |
| Wall thickness of wall (mm) | 30 |
| Wall thickness of roof (mm) | 30 |
| Wall thickness of floor (mm) | 38 |
| Fresh water tank (l)( 5 ) | 140 ltr. |
| Battery capacity (Ah) | 1 x 80 Ah Gel |
| Water volume in drive position (l) | 100 ltr. |
(1)Dimensions in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard features according to the manufacturer specifications, 90% of the fill capacity for fuel, 75 kg (weight of the driver), water in drive position and gas (11 kg gas cylinder made of aluminium), without special features
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: Only with seat belts facing away from the direction of travel and 40 H chassis | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Engine
| serial/optional | |
|---|---|
| Fiat 180 HP motor (surcharge compared to 140 HP) | optional |
| Fiat 140 HP motor | serial |
Other options
| serial/optional | |
|---|---|
| Fiat automatic transmission | optional |
| Reinforced front axle springs | optional |
| Fuel tank, 90 litre | optional |
| Heavy Duty | optional |
Total mass
| serial/optional | |
|---|---|
| Maxi chassis 4.25t | optional |
| Maxi chassis 4.4t | optional |
| Increase of total mass to 3.65t | optional |
| Reduction of total mass to 3.5 t | optional |
Exterior
| serial/optional | |
|---|---|
| Spare wheel | optional |
| Superstructure door with central locking | optional |
| Rear design package | optional |
| Rear comfort supports | optional |
| Trailer coupling | optional |
| Roof-mounted air-conditioning system 230 Volt | optional |
| Roof-mounted air-conditioning system 230 Volt (surch. Mond.) | optional |
| External shower (cold/warm) | optional |
| Window in toilet room | optional |
| Sunroof panoramic glass roof | optional |
| Electric roof fan | optional |
| Tilting roof hood (Heki) | optional |
Equipment packages
| serial/optional | |
|---|---|
| Fiat Driving assistance package | optional |
| Fiat Driving assistance plus package | optional |
| Mondial package Profila T Fiat (moniceiver with rear-view camera (Xzent), electric external mirrors, Captain's chair seats, steering wheel controls, electric parking brake, radiator grille painted in piano black paint, tilting roof hood (Heki), electric roof fan, superstructure door with central locking, mesh screen for body door, pre-cabling for solar power system, sunroof panoramic glass roof, driver's cab dimming system, radio preparation incl. DAB+) | optional |
| Mondial-Plus Package Profila T Truma (naviceiver with twin eye rear-view camera, automatic air conditioning, leather steering wheel and gearshift knob, 16 aluminium rims, inductive charging station, carpet in the driver’s cab, multi-function socket, external shower (hot/cold), external gas socket, driver cab all-round insulated curtain, heat exchanger, combi 6 E heating, rear design package, Lithium battery (1x)) | optional |
Multimedia
| serial/optional | |
|---|---|
| Loudspeakers (2) in superstr. | optional |
| Flat screen wall bracket in front area | optional |
Interior
| serial/optional | |
|---|---|
| Driver cab all-round insulated curtain | optional |
| Driver's cab dimming system | optional |
| Mesh screen for cabin door | optional |
| Driver cab seats in superstructure upholstery | serial |
| Additional bed for 2 people (conversion of seating group) | optional |
| Cot in driver's cabin | optional |
| Carpeted floor in superstructure | optional |
| Seat: Fifth seat | optional |
| Background lighting | serial |
Additional optional extras
| serial/optional | |
|---|---|
| Bedspread on QB/HB | optional |
| Maka décor | serial |
| Lasca décor | optional |
| Rana décor | optional |
| Evono décor | optional |
Bicycle carrier
| serial/optional | |
|---|---|
| Bike carrier extension kit 4-way | optional |
| Bike carrier for 2 bikes | optional |
| Lowerable E-bikes carrier | optional |
Sunblinds
| serial/optional | |
|---|---|
| 4 m canopy | optional |
Technical services
| serial/optional | |
|---|---|
| Multi-function socket | optional |
| Heat exchanger | optional |
| Lithium battery (1x) | optional |
| Lithium batteries (2x) | optional |
| 2nd gel battery - 80 Ah | optional |
| Pre-cabling for solar power system | optional |
| External gas socket | optional |
| Duo Control CS with ice-ex | optional |
| Waste water tank, insulated and heated | serial |
Fabrics
| serial/optional | |
|---|---|
| Milano upholstery fabric | optional |
| Trail upholstery fabric | optional |
| Dara upholstery fabric | optional |
| Bergamo upholstery fabric | optional |
| Pisa upholstery fabric | optional |
| Como upholstery fabric | serial |
Furniture
| serial/optional | |
|---|---|
| Chalet furniture décor | serial |
Heating
| serial/optional | |
|---|---|
| Warm air heating | serial |
| Combi 6 E heating | optional |
Kitchen
| serial/optional | |
|---|---|
| Extractor hood | optional |
| Oven | optional |
| Large refrigerator | serial |
Versicherungsprodukte
| serial/optional | |
|---|---|
| 1 year follow-on guarantee < 4.5t | optional |
| 2 year follow-on guarantee < 4.5t | optional |
Additional products
| serial/optional | |
|---|---|
| Reduction of travel seats by 1 | optional |
| Reduct. of travel seats by 2 | optional |
| Reduction of travel seats by 3 | optional |
| Reduction of travel seats by 4 | optional |
