Profila T 676 EB
Technical data
Basic vehicle | Mercedes Benz / AL-KO low-slung frame |
---|---|
Engine models | 150 PS |
Engine models (optional) | 125 kW (170 HP) |
Double floor height (mm) | 195 |
Wheelbase (mm) | 4110 |
Tyres | 235/60 R17C |
Total techn. perm. Weight when laden (kg) | 3.500 / 4.500 (Option) |
Weight in ready-to-drive state* (kg)( 1 ) | 2995 kg |
Trailer weight* (braked) (kg)( 2 ) | 1800 / 2000 kg |
Total length (mm) | 7120 |
Total width (mm) | 2322 |
Total height (mm) | 2920 |
Interior width (mm) | |
Standing height (mm) | 1980 |
Front side seating group (mm) | 1150 x 1050 |
Bed conversion of the seating group (mm)( 3 ) | 1150 x 2000 |
Rear bed (mm) | 1950 x 800 / 1950 x 800 |
Lift-up bed (mm) | |
Extension to X sleeping areas | 4 |
Permissible number of people with 3-point seatbelts total* | 4 |
Seat extension to X persons( 4 ) | - |
Wall thickness of wall (mm) | 30 |
Wall thickness of roof (mm) | 30 |
Wall thickness of floor (mm) | 38 |
Fresh water tank (l)( 5 ) | 140 ltr. |
Battery capacity (Ah) | 1 x 80 Ah Gel |
Water volume in drive position (l) | 100 ltr. |
(1)Dimensions in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard equipment as per manufacturer specifications, 90 % of the fill capacity for fuel, 100% of water in drive position and gas (11 kg gas cylinder made of aluminium), without optional equipment
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: only with 2-point lap belts facing away from the direction of travel | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Engine
serial/optional | |
---|---|
Mercedes-Benz 143 HP motor | serial |
Mercedes-Benz 170 HP motor | optional |
Other options
serial/optional | |
---|---|
Mercedes Benz 9G-Tronic automatic transmission | optional |
Fuel tank, 92 litre | optional |
Exterior
serial/optional | |
---|---|
Superstructure door with central locking | serial |
Rear comfort supports | optional |
Trailer coupling | optional |
Roof-mounted air-conditioning system 230 Volt | optional |
Sun Roof panoramic roof window, insulated and adjustable | optional |
Electric roof fan | optional |
Tilting roof hood (Heki) | optional |
Garage door service flap | serial |
Multimedia
serial/optional | |
---|---|
Loudspeakers (2) in superstr. | optional |
Moniceiver with rear-view camera | optional |
Flat screen pull-out in front area | optional |
Interior
serial/optional | |
---|---|
Driver cab all-round insulated curtain | optional |
Driver's cab dimming system | serial |
Mesh screen for cabin door | optional |
Additional bed for 2 people (conversion of seating group) | optional |
Carpeted floor in superstructure | optional |
Background lighting | serial |
Heating
serial/optional | |
---|---|
Driver cab floor heating (heated floor mat / Alde heating) | optional |
Hot water heating - Alde | serial |
Bicycle carrier
serial/optional | |
---|---|
Bike carrier extension kit 4-way | optional |
Bike carrier for 2 bikes | optional |
Lowerable E-bikes carrier | optional |
Sunblinds
serial/optional | |
---|---|
4 m canopy | optional |
Technical services
serial/optional | |
---|---|
Multi-function socket | optional |
External shower (cold/warm) | optional |
Lithium battery (1x) | optional |
Lithium batteries (2x) | optional |
2nd gel battery - 80 Ah | optional |
Pre-cabling for solar power system | optional |
Autonomous E-bike charger | optional |
External gas socket | optional |
Duo-control CS with ice-ex | optional |
Toilet ventilation (SOG system) | optional |
Additional products
serial/optional | |
---|---|
Driver cab seats in superstructure upholstery | serial |
Maka deco | optional |
Lasca deco | optional |
Rana deco | optional |
Reduction of travel seats by 1 | optional |
Reduct. of travel seats by 2 | optional |
Reduction of travel seats by 3 | optional |
Reduction of travel seats by 4 | optional |
Fabrics
serial/optional | |
---|---|
Milano upholstery fabric | optional |
Dara upholstery fabric | optional |
Pisa upholstery fabric | optional |
Leather beige upholstery fabric | optional |
Leather grey upholstery fabric | optional |
Como upholstery fabric | serial |
Furniture
serial/optional | |
---|---|
Chalet furniture | serial |
Kitchen
serial/optional | |
---|---|
Extractor hood | optional |
Large refrigerator | serial |
Equipment packages
serial/optional | |
---|---|
Mondial package PT MB (Uni black paintwork, Driver's cab air conditioning system, Electric parking brake, Moniceiver with rear-view camera, Cruise control, Electric external mirrors, Body door with 2-point locking system, Sunroof panoramic roof window (can be opened), Electric roof fan, Driver's cab darkening (windscreen and side windows), Mesh door screen, Pre-cabling for solar power system + TV, Carpet in the driver’s cab, Exclusive design package) | optional |
Mondial Plus package PT MB (Storage compartment under cockpit, Acoustic package (engine noise insulation), Thermotronic automatic air conditioning, Dashboard charging package, Leather steering wheel, Inductive charging station, Heat-insulating glass, 16 inch alloy wheels, Automatic transmission, 170 HP engine, Multi-function socket, External shower (cold/warm), SOG toilet ventilation, Outside gas socket, Awning, Duo control with remote display, de-icer and crash sensor, Multi-function steering wheel, Navigation device, incl. dual-eye, rear view camera) | optional |
