Van V 595 HB
360° Panorama:
Please click the button below to load the content from Matterport Panorama.
With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren
Technical data
| Basic vehicle | Fiat Ducato 35L // 35H |
|---|---|
| Engine models | 120 HP |
| Engine models (optional) | 140 HP, 180 HP |
| Double floor height (mm) | |
| Wheelbase (mm) | 4035 |
| Tyres | 215/70 R15 // 225/75 R16C |
| Total techn. perm. Weight when laden (kg) | 3500 kg |
| Weight in ready-to-drive state* (kg)( 1 ) | 2.945 kg |
| Trailer weight* (braked) (kg)( 2 ) | 2.500 // 3.000 kg |
| Total length (mm) | 5990 |
| Total width (mm) | 2050 |
| Total height (mm) | 2650 |
| Interior width (mm) | 1940 |
| Standing height (mm) | 1890 |
| Front side seating group (mm) | |
| Bed conversion of the seating group (mm)( 3 ) | |
| Rear bed (mm) | 1.860 x 1.490 |
| Coachbuild bed / Lift-up bed (mm) | |
| Extension to X sleeping areas | 3 |
| Permissible number of people with 3-point seatbelts total* | 4 |
| Seat extension to X persons( 4 ) | - |
| Wall thickness of wall (mm) | |
| Wall thickness of roof (mm) | |
| Wall thickness of floor (mm) | |
| Fresh water tank (l)( 5 ) | 85 ltr. |
| Battery capacity (Ah) | 1 x 100 Ah Gel |
| Water volume in drive position (l) | 75 ltr. |
(1)Dimensions in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard features according to the manufacturer specifications, 90% of the fill capacity for fuel, 75 kg (weight of the driver), water in drive position and gas (11 kg gas cylinder made of aluminium), without special features
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: Only with seat belts facing away from the direction of travel and 40 H chassis | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Engine
| serial/optional | |
|---|---|
| 120PS Engine Fiat | serial |
| 140PS Engine Fiat (AP 120PS) | optional |
| Fiat 180 HP engine (surcharge to 140 HP) | optional |
Other options
| serial/optional | |
|---|---|
| Fiat automatic gearbox | optional |
| 90l Tank | serial |
| Fog light | optional |
| Electrical retraction of exterior mirrors | optional |
| Electrically height-adjustable exterior mirrors | optional |
| Blind spot assistant with rear lateral movement detection | optional |
| Inductive charging station | optional |
| Electric parking brake | optional |
| Parking assistance | optional |
| Automatic air conditioning | optional |
| Black radiator grille | optional |
| Steering wheel and gearshift knob in leather | optional |
Wheels
| serial/optional | |
|---|---|
| 16 inch aluminium rims | optional |
Total mass
| serial/optional | |
|---|---|
| Body 35 H | optional |
Paint finish
| serial/optional | |
|---|---|
| Fiat White paintwork | serial |
| Fiat Iron Grey paintwork | optional |
| Fiat Black paintwork | optional |
| Artense Grey paintwork | optional |
| Expedition Grey paintwork | optional |
| Lanzarote Grey paintwork | optional |
Equipment packages
| serial/optional | |
|---|---|
| Driving assistance package (Emergency breaking and lane keeping assistant, Rain and light sensor, High beam assistant, Traffic sign recognition, Blind spot assistant with rear lateral movement detection, Parking assistance) | optional |
| Driving assistance plus package (Emergency braking and lane keeping assistant, Rain and light sensor, High beam assistant, Traffic sign recognition, Blind spot assistant with rear lateral movement detection, Parking assistance, Adaptive cruise control, Intelligent speed assistant, Fatigue recognition) | optional |
| Mondial Package Eura Mobil Van (140 HP engine, 16 inch aluminium rims, 7 inch DAB radio, DAB preparation, Fiat rear-view camera, Electrically height-adjustable exterior mirrors, Electrical retraction of exterior mirrors, Fog light, Black radiator grille, Headlights with black frame, Electric parking brake, Keyless Entry and Go, Solar system, Roof - panoramic roof/Skyroof, Driver cab dimming system, Awning, Mesh screen for cabin door) | optional |
| Mondial Plus Package Eura Mobil Van (140 HP engine, 16 inch aluminium rims, 10 inch DAB radio, DAB preparation, Fiat rear-view camera, Electrically height-adjustable exterior mirrors, Electrical retraction of exterior mirrors, Fog light, Black radiator grille, Headlights with black frame, Electric parking brake, Keyless Entry and Go, Solar system, Roof - panoramic roof/Skyroof, Driver cab dimming system, Awning, Mesh screen for cabin door, automatic air conditioning, LED headlights, Steering wheel and gearshift knob in leather, inductive charging station, fully digital display) | optional |
Multimedia
| serial/optional | |
|---|---|
| 7 Inch DAB Radio | optional |
| 10 Inch DAB Radio + Navigation | optional |
| DAB Preparation | optional |
| Flat screen wall bracket in front area | optional |
Interior
| serial/optional | |
|---|---|
| Manual blackout system | optional |
| Mesh screen for cabin door | optional |
| Additional bed (conversion of seating group) for one person | optional |
Bicycle carrier
| serial/optional | |
|---|---|
| Bicycle carrier for 2 bicycles (up to 30 kg) | optional |
Exterior
| serial/optional | |
|---|---|
| Roof - Sun Roof / Skyroof panoramic plastic roof | optional |
| Midi-Heki skylight | serial |
Technical services
| serial/optional | |
|---|---|
| Solar system | serial |
Sunblinds
| serial/optional | |
|---|---|
| 3.7 m mechanical canopy | optional |
Heating
| serial/optional | |
|---|---|
| Combi C 6 E heating | optional |
| Combi D 6 E heating | optional |
Additional products
| serial/optional | |
|---|---|
| 1 year follow-on guarantee < 4.5t | optional |
| 2 year follow-on guarantee < 4.5t | optional |
| 3 year follow-on guarantee < 4.5t | optional |
