CT 766 EB
Length: 7,84 m
Sleeping areas: 2
CT 766 EB
360° Panorama
Please click the button below to load the content from Matterport Panorama.
With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren
Technical data
Basic vehicle | Mercedes Benz / AL-KO |
---|---|
Engine models | 2,0 ltr. |
Engine models (optional) | 2,0 ltr. |
Double floor height (mm) | 195 |
Wheelbase (mm) | 4450 |
Tyres | 225/75 R16C(235/60 R17C) |
Total techn. perm. Weight when laden (kg)( 1 ) | 4500 kg |
Weight in ready-to-drive state* (kg)( 2 ) | 3132 (2975 - 3289) |
Trailer weight* (braked) (kg) | 2000 kg |
Maximum dimensions for packages and optional extras( 4 ) | 886,00 |
Total length (mm) | 7844 |
Total width (mm) | 2322 |
Total height (mm) | 2920 |
Interior width (mm) | 2174 |
Standing height (mm) | 1975 |
Front side seating group (mm) | 1150 x 1050 |
Bed conversion of the seating group (mm)( 3 ) | 1900 x 1000 |
Rear bed (mm) | 1950 x 8002000 x 800 |
Extension to X sleeping areas | 4 |
Permissible number of people with 3-point seatbelts total*( 3 ) | 4 |
Wall thickness of wall (mm) | 30 |
Wall thickness of roof (mm) | 30 |
Wall thickness of floor (mm) | 38 |
Fresh water tank (l)( 5 ) | 140 ltr. |
Waste water tank (l)( 5 ) | 10 ltr. |
Battery capacity (Ah) | 1 x 80 AH Gel |
Water volume in drive position (l) | 88 ltr. |
(1)The technically permissible overall weight in a laden state refers to the overall weight defined by the manufacturer that the vehicle may not exceed when in drive mode.
(2)The weight in ready-to-drive state refers to the weight of the vehicle (with standard features according to the manufacturer's specifications) with its fuel tank filled to at least 90% of capacity and includes the weight of the driver (which is calculated at a nominal value of 75 kg), the weight of the fuel and fluids, the weight of the superstructure and the driver's cab, and the weight of the towing hitch and the tyre repair kit (to the extent these are present). This represents a calculated value that is subject to legally permissible fluctuations of up to ± 5% (see additional text in brackets). Since these legally permissible fluctuations impact the vehicle's payload and therefore also the weights of the packages and special equipment that can be ordered, the occurrence of such fluctuations must be factored into the configuration process and the choice of packages and special equipment.
(3)The weight of the passengers is calculated at a nominal 75 kg per seat, whereas the weight of the driver, which was already taken into account in the weight in the ready-to-drive state, must be deducted. In the case of a vehicle with four belt-restrained seats, the weight of the passengers is therefore 225 kg (3 x 75 kg).
(4)The maximum weights for packages and special equipment represent a value calculated for each floor plan with which we have restricted the weights for the packages and special equipment that can be ordered from the factory. This is intended to ensure that the legally prescribed minimum payload is complied with after the vehicle is shipped from the factory. If the configuration process leads to the upper limit for this defined by the manufacturer being exceeded as a result of the choice of packages and special equipment, you can only continue with the configuration process if you de-select packages, special equipment or belt-restrained seats or choose to in-crease the vehicle's load capacity. Otherwise, you will not be able to configure or ordering the configured vehicle. Please note that the calculation of the maximum weights for packages and special equipment also takes into account the special equipment features of the selected country variation / the selected special model. The selected vehicle is currently shown in the country variation United Kingdom. Important information regarding vehicle weights can be found here
(5)Please note that the capacity of the fresh water tank is significantly reduced in the drive position. If the payload of the individual vehicle is sufficient, it can be filled to its full capacity.
Equipment
Engine
serial/optional | |
---|---|
Mercedes-Benz 170 HP motor | serial |
Other options
serial/optional | |
---|---|
Mercedes Benz 9G-Tronic automatic transmission | serial |
Fuel tank, 92 litre | serial |
Paint finish
serial/optional | |
---|---|
Obsidian black paintwork | serial |
Exterior
serial/optional | |
---|---|
Superstructure door with central locking | serial |
Heatable windscreen | optional |
Exclusive rear design | optional |
Rear comfort supports | optional |
Trailer coupling | optional |
Roof-mounted air-conditioning system 230 Volt | optional |
Window in toilet room | serial |
Starlight Dome panor. roof w. smart lift & soft close funct. | serial |
Adjustable roof hood | serial |
Electric roof fan | serial |
Mesh screen for body door | serial |
Garage door service flap | serial |
Equipment packages
serial/optional | |
---|---|
MB driving assist. Package CT (Active lane departure warning, High beam assistant, Tire pressure sensors, fog lights, High performance LED head lights) | optional |
Luminary Package Contura (bumpers and attachment parts in vehicle colour, electric external mirrors, 17 aluminium rims, Comfort seats, MBUX 10 Naviceiver with twin eye rear-view camera, electric parking brake, chrome-plated radiator grille, Mercedes Benz 9G-Tronic automatic transmission Mercedes-Benz, 170 HP motor, 92 litre fuel tank, heat-insulating glass with band filter, Carbon external décor, storage compartment under cockpit, flap cover for storage compartments, acoustic package, Climatronic automatic air conditioning, dashboard charging package, leather steering wheel, inductive charging station, traffic sign assistant, Distronic active distance assistant, Adjustable roof hood, Obsidian black paintwork, Superstructure door with central locking, Starlight Dome, Electric roof fan, Manual blackout system, Mesh screen for body door, Pre-cabling for solar power system, Extractor hood) | optional |
Luminary-Plus Package Contura (carpet in the driver’s cab, Multi-function socket, External shower (cold/warm), External gas socket, Driver cab insulated curtain, Lithium battery) | optional |
Multimedia
serial/optional | |
---|---|
Sound system | optional |
Flat screen wall bracket in front area | optional |
Flat screen wall bracket in rear area | optional |
Interior
serial/optional | |
---|---|
Comfort seat | serial |
Driver cab all-round insulated curtain | serial |
Driver cab floor heating (heated floor mat / Alde heating) | optional |
Cab floormat | serial |
Driver's cab dimming system | serial |
Protective cover in superstructure upholstery for cab seats | serial |
Additional bed for 2 people (conversion of seating group) | optional |
Cot in driver's cabin | optional |
Table with chrome-plated table pedestal | serial |
Background lighting | serial |
Additional optional extras
serial/optional | |
---|---|
Integra/Contura on EB bedspread | optional |
Maka décor | serial |
Lasca décor | optional |
Rana décor | optional |
Bicycle carrier
serial/optional | |
---|---|
Bicycle carrier for 2 bicycles or 2 E-bikes (up to 60 kg) | optional |
Bike carrier extension kit 4-way | optional |
Sunblinds
serial/optional | |
---|---|
5 m canopy | optional |
Technical services
serial/optional | |
---|---|
Multi-function socket | serial |
Underfloor camera for electrical tank emptying | optional |
External shower (cold/warm) | serial |
Lithium battery (1x) | serial |
Lithium batteries (2x) | optional |
2nd gel battery - 80 Ah | optional |
Pre-cabling for solar power system | serial |
Autonomous E-bike charger | optional |
External gas socket | serial |
Duo Control CS with ice-ex | serial |
Fabrics
serial/optional | |
---|---|
Milano upholstery fabric | optional |
Upholstery "Glendale" | optional |
Dara upholstery fabric | optional |
Pisa upholstery fabric | optional |
Leather beige upholstery fabric | optional |
Leather grey upholstery fabric | optional |
Como upholstery fabric | serial |
Furniture
serial/optional | |
---|---|
Navarra furniture décor | serial |
Kitchen
serial/optional | |
---|---|
Extractor hood | serial |
Oven | optional |
Large refrigerator | serial |
Versicherungsprodukte
serial/optional | |
---|---|
2 year follow-on guarantee < 4.5t | optional |
3 year follow-on guarantee < 4.5t | optional |
Additional products
serial/optional | |
---|---|
Reduction of travel seats by 1 | optional |
Reduct. of travel seats by 2 | optional |
Reduction of travel seats by 3 | optional |
Reduction of travel seats by 4 | optional |
