Profila RS 695 HB
Panorama will be available soon
Technical data
| Basic vehicle | Fiat Ducato / 3,5 t / Fiat CCS low-slung frame |
|---|---|
| Engine models | 103 kW, 140 HP |
| Engine models (optional) | 130 kW, 180 HP |
| Double floor height (mm) | 110 |
| Wheelbase (mm) | 4035 |
| Tyres | 225/75 R16C |
| Total techn. perm. Weight when laden (kg) | 3500 / 4250 / 4400 kg |
| Weight in ready-to-drive state* (kg)( 1 ) | 3000 kg |
| Trailer weight* (braked) (kg)( 2 ) | 2000 / 1800 / 1750 kg |
| Total length (mm) | 6990 |
| Total width (mm) | 2322 |
| Total height (mm) | 3000 |
| Interior width (mm) | 2174 |
| Standing height (mm) | 1975 |
| Front side seating group (mm) | 1150 x 1050 |
| Bed conversion of the seating group (mm)( 3 ) | 2000 x 1150 |
| Rear bed (mm) | 1500 x 1900 |
| Coachbuild bed / Lift-up bed (mm) | 1930 x 1400 |
| Extension to X sleeping areas | 6 |
| Permissible number of people with 3-point seatbelts total* | 4 |
| Seat extension to X persons( 4 ) | 5 (only in conjunction with superimposed load to 3.65 t) |
| Wall thickness of wall (mm) | 30 |
| Wall thickness of roof (mm) | 30 |
| Wall thickness of floor (mm) | 38 |
| Fresh water tank (l)( 5 ) | 140 ltr. |
| Battery capacity (Ah) | 1 x 80 Ah Gel |
| Water volume in drive position (l) | 100 ltr. |
(1)Dimensions in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard features according to the manufacturer specifications, 90% of the fill capacity for fuel, 75 kg (weight of the driver), water in drive position and gas (11 kg gas cylinder made of aluminium), without special features
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: Only with seat belts facing away from the direction of travel and 40 H chassis | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Engine
| serial/optional | |
|---|---|
| Fiat 180 HP motor (surcharge compared to 140 HP) | optional |
| Fiat 140 HP motor | serial |
| Heavy Duty | optional |
Other options
| serial/optional | |
|---|---|
| Fiat automatic transmission | optional |
| Spare wheel | optional |
| Reinforced front axle springs | optional |
| Fuel tank, 90 litre | optional |
Total mass
| serial/optional | |
|---|---|
| Maxi chassis 4.4t | optional |
| Increase of total mass to 3.65t | optional |
| Reduction of total mass to 3.5 t | optional |
Exterior
| serial/optional | |
|---|---|
| Superstructure door with central locking | optional |
| Rear design package | optional |
| Rear comfort supports | optional |
| Trailer coupling | optional |
| Roof-mounted air-conditioning system 230 Volt | optional |
| Roof-mounted air-conditioning system 230 Volt (surch. Mond.) | optional |
| Sunroof panoramic glass roof | optional |
| Electric roof fan | optional |
| Garage door service flap | serial |
Equipment packages
| serial/optional | |
|---|---|
| Fiat Driving assistance package (Emergency braking and lane departure assistant, Rain and light sensor, Traffic sign recognition, Automatic dimming) | optional |
| Fiat Driving assistance plus package (Emergency braking and lane departure assistant, Rain and light sensor, Traffic sign recognition, Automatic dimming, Adaptive cruise control, Intelligent speed assistant, Fatigue assistant) | optional |
| Mondial Package Profila RS (Moniceiver with rear-view camera, Electric external mirrors, Captain's chair seats, Bumpers painted in the vehicle colour, Radiator grille in piano black, Headlights with black frame, Steering wheel controls, 16 inch aluminium rims, Electric parking brake, Fog lights with cornering light, Carpet in the driver’s cab, Tilting roof hood (Heki), Electric roof fan, Sunroof panoramic glass roof, Superstructure door with central locking, Mesh screen for cabin door, Pre-cabling for solar power system, Driver cab dimming system, Exclusive rear design) | optional |
| Mondial Plus Package Profila RS Truma (Moniceiver with rear-view camera, Electric external mirrors, Captain's chair seats, Bumpers painted in the vehicle colour, Radiator grille in piano black, Headlights with black frame, Steering wheel controls, 16 inch aluminium rims, Electric parking brake, Fog lights with cornering light, Carpet in the driver’s cab, Tilting roof hood (Heki), Electric roof fan, Sunroof panoramic glass roof, Superstructure door with central locking, Mesh screen for cabin door, Pre-cabling for solar power system, Driver cab dimming system, Exclusive rear design, Automatic air conditioning, Leather steering wheel and gearshift knob, Multi-function exterior socket, Toilet ventilation (SOG), External shower (cold/warm), External gas socket, Dual-control CS with de-icer, All-round insulation in the driver cab, Mechanical canopy, Combi 6 E heating (with warm air heating)) | optional |
Multimedia
| serial/optional | |
|---|---|
| Loudspeakers (2) in superstr. | optional |
| Moniceiver with rear-view camera | optional |
| Naviceiver with rear-view camera | optional |
| Flat screen wall bracket in front area | optional |
Interior
| serial/optional | |
|---|---|
| Driver cab all-round insulated curtain | optional |
| Driver's cab dimming system | optional |
| Mesh screen for cabin door | optional |
| Additional bed for 2 people (conversion of seating group) | optional |
| Electrically adjustable lift-up bed | optional |
| Carpeted floor in superstructure | optional |
| Seat: Fifth seat | optional |
Bicycle carrier
| serial/optional | |
|---|---|
| Bike carrier extension kit 4-way | optional |
| Bike carrier for 2 bikes | optional |
| Lowerable E-bikes carrier | optional |
Sunblinds
| serial/optional | |
|---|---|
| 4 m canopy | optional |
Technical services
| serial/optional | |
|---|---|
| Multi-function socket | optional |
| External shower (cold/warm) | optional |
| Heat exchanger | optional |
| Lithium battery (1x) | optional |
| Lithium batteries (2x) | optional |
| 2nd gel battery - 80 Ah | optional |
| Pre-cabling for solar power system | optional |
| Autonomous E-bike charger | optional |
| External gas socket | optional |
| Duo-control CS with ice-ex | optional |
| Toilet ventilation (SOG system) | optional |
| Waste water tank, insulated and heated | serial |
| Background lighting | serial |
Additional optional extras
| serial/optional | |
|---|---|
| Driver cab seats in superstructure upholstery | serial |
| Maka décor | serial |
| Lasca décor | optional |
| Rana décor | optional |
| Reduction of travel seats by 1 | optional |
| Reduct. of travel seats by 2 | optional |
| Reduction of travel seats by 3 | optional |
| Reduction of travel seats by 4 | optional |
Fabrics
| serial/optional | |
|---|---|
| Milano upholstery fabric | optional |
| Dara upholstery fabric | optional |
| Pisa upholstery fabric | optional |
| Como upholstery fabric | serial |
Furniture
| serial/optional | |
|---|---|
| Chalet furniture décor | serial |
Heating
| serial/optional | |
|---|---|
| Warm air heating | serial |
| Combi 6 E heating | optional |
Kitchen
| serial/optional | |
|---|---|
| Extractor hood | optional |
| Oven | optional |
| Large refrigerator | serial |
Additional products
| serial/optional | |
|---|---|
| 1 year follow-on guarantee < 4.5t | optional |
| 2 year follow-on guarantee < 4.5t | optional |
| 3 year follow-on guarantee < 4.5t | optional |
