Activa One 650 HS
360° Panorama:
Please click the button below to load the content from Matterport Panorama.
With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren
Technical data
| Basic vehicle | Fiat Ducato / 3,5 t / Fiat CCS low-slung frame |
|---|---|
| Engine models | 103 kW, 140 HP |
| Engine models (optional) | 130 kW, 180 HP |
| Double floor height (mm) | 370 |
| Wheelbase (mm) | 3800 |
| Tyres | 225/75 R16C |
| Total techn. perm. Weight when laden (kg) | 3500 / 4250 / 4400 kg |
| Weight in ready-to-drive state* (kg)( 1 ) | 2860 kg |
| Trailer weight* (braked) (kg)( 2 ) | 2000 / 1800 / 1750 kg |
| Total length (mm) | 6500 |
| Total width (mm) | 2322 |
| Total height (mm) | 3150 |
| Interior width (mm) | 2174 |
| Standing height (mm) | 1975 |
| Front side seating group (mm) | - |
| Bed conversion of the seating group (mm)( 3 ) | 2000 x 1400 |
| Rear bed (mm) | - |
| Coachbuild bed / Lift-up bed (mm) | 2000 x 800, 2000 x 800 |
| 2000x1500 // 2x 2000x800 | |
| Extension to X sleeping areas | - |
| Permissible number of people with 3-point seatbelts total* | 4 |
| Seat extension to X persons( 4 ) | - |
| Wall thickness of wall (mm) | 30 |
| Wall thickness of roof (mm) | 30 |
| Wall thickness of floor (mm) | 38 |
| Fresh water tank (l)( 5 ) | 150 ltr. |
| Battery capacity (Ah) | 1 x 80 Ah Gel |
| Water volume in drive position (l) | 150 ltr. |
(1)Dimensions in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard features according to the manufacturer specifications, 90% of the fill capacity for fuel, 75 kg (weight of the driver), water in drive position and gas (11 kg gas cylinder made of aluminium), without special features
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: Only with seat belts facing away from the direction of travel and 40 H chassis | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Engine
| serial/optional | |
|---|---|
| Fiat 180 HP motor (surcharge compared to 140 HP) | optional |
| Fiat 140 HP motor | serial |
| Heavy Duty | optional |
Other options
| serial/optional | |
|---|---|
| Fiat automatic transmission | optional |
| Spare wheel | optional |
| Reinforced front axle springs | optional |
| Fuel tank, 90 litre | optional |
Total mass
| serial/optional | |
|---|---|
| Maxi chassis 4.4t | optional |
| Increase of total mass to 3.65t | optional |
| Reduction of total mass to 3.5 t | optional |
Exterior
| serial/optional | |
|---|---|
| Superstructure door with central locking | optional |
| Rear comfort supports | optional |
| Trailer coupling | optional |
| Sunroof panoramic glass roof | optional |
| Electric roof fan | optional |
| Tilting roof hood (Heki) | optional |
| Service flap at the rear | optional |
Equipment packages
| serial/optional | |
|---|---|
| Fiat Driving assistance package (Emergency braking and lane departure assistant, Rain and light sensor, Traffic sign recognition, Automatic dimming) | optional |
| Fiat Driving assistance plus package (Emergency braking and lane departure assistant, Rain and light sensor, Traffic sign recognition, Automatic dimming, Adaptive cruise control, Intelligent speed assistant, Fatigue assistant) | optional |
| Décor package for rear seating group | optional |
| Travel Package AO570HS/AO650HS (Moniceiver with rear-view camera, Electric external mirrors, Captain's chair seats, Bumpers painted in the vehicle colour, Steering wheel controls, 16 inch aluminium rims, Electric parking brake, Carpet in the driver’s cab, Tilting roof hood (Heki), Ambient lighting, Service flap or garage door in the rear (through-loading option to double floor – depending on size and floor plan), Driver cab dimming system (for windscreen & side windows), Mesh screen for cabin door, Pre-cabling for solar power system, Radio preparation incl. DAB) | optional |
| Travel Plus Package AO650HS (Moniceiver with rear-view camera, Electric external mirrors, Captain's chair seats, Bumpers painted in the vehicle colour, Steering wheel controls, 16 inch aluminium rims, Electric parking brake, Carpet in the driver’s cab, Tilting roof hood (Heki), Ambient lighting, Service flap or garage door in the rear (through-loading option to double floor – depending on size and floor plan), Driver cab dimming system (for windscreen & side windows), Mesh screen for cabin door, Pre-cabling for solar power system, Radio preparation incl. DAB, Heat exchanger, Automatic air conditioning, Leather steering wheel and gearshift knob, Multi-function exterior socket, Toilet ventilation (SOG), External shower (cold/warm), External gas socket, Insulated curtain (All-round insulation in the driver cab), Dual-control CS with de-icer & crash sensor, Combi 6 E heating, Mechanical canopy) | optional |
Multimedia
| serial/optional | |
|---|---|
| Loudspeakers (2) in superstr. | optional |
| Moniceiver with rear-view camera | optional |
| Naviceiver with rear-view camera | optional |
| Flat screen wall bracket in rear area | optional |
Interior
| serial/optional | |
|---|---|
| Driver cab all-round insulated curtain | optional |
| Driver's cab dimming system | optional |
| Mesh screen for cabin door | optional |
| Additional bed for 2 people (conversion of seating group) | serial |
| Carpeted floor in superstructure | optional |
| Safety belts and head rests in direction of travel at rear | serial |
Bicycle carrier
| serial/optional | |
|---|---|
| Bike carrier extension kit 4-way | optional |
| Bike carrier for 2 bikes | optional |
Sunblinds
| serial/optional | |
|---|---|
| 4 m canopy | optional |
Technical services
| serial/optional | |
|---|---|
| Multi-function socket | optional |
| External shower (cold/warm) | optional |
| Heat exchanger | optional |
| Lithium battery (1x) | optional |
| Lithium batteries (2x) | optional |
| 2nd gel battery - 80 Ah | optional |
| Pre-cabling for solar power system | optional |
| Autonomous E-bike charger | optional |
| External gas socket | optional |
| Duo-control CS with ice-ex | optional |
| Toilet ventilation (SOG system) | optional |
| Background lighting | optional |
Additional optional extras
| serial/optional | |
|---|---|
| Driver cab seats in superstructure upholstery | optional |
| Maka décor | serial |
| Lasca décor | optional |
| Reduction of travel seats by 1 | optional |
| Reduct. of travel seats by 2 | optional |
| Reduction of travel seats by 3 | optional |
| Reduction of travel seats by 4 | optional |
Fabrics
| serial/optional | |
|---|---|
| Milano upholstery fabric | optional |
| Dara upholstery fabric | serial |
Furniture
| serial/optional | |
|---|---|
| Beach Home furniture décor | serial |
Heating
| serial/optional | |
|---|---|
| Warm air heating | serial |
| Combi 6 E heating | optional |
Kitchen
| serial/optional | |
|---|---|
| Extractor hood | optional |
| Oven | optional |
| Large refrigerator | serial |
Additional products
| serial/optional | |
|---|---|
| 1 year follow-on guarantee < 4.5t | optional |
| 2 year follow-on guarantee < 4.5t | optional |
| 3 year follow-on guarantee < 4.5t | optional |
Configure your motorhome
Choose one of our models and modify it to your individual preferences.
