Integra Line 720 EF
360° Panorama:
Please click the button below to load the content from Matterport Panorama.
With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren
Technical data
| Basic vehicle | Fiat Ducato |
|---|---|
| Engine models | 2,2 ltr. |
| Engine models (optional) | 2,2 ltr. |
| Double floor height (mm) | 110 |
| Wheelbase (mm) | 4035 |
| Tyres | 225/75 R16C |
| Total techn. perm. Weight when laden (kg) | 3500 / 4250 / 4400 kg |
| Weight in ready-to-drive state* (kg)( 1 ) | 3180 kg |
| Trailer weight* (braked) (kg)( 2 ) | 2000 / 1800 / 1750 kg |
| Total length (mm) | 7407 |
| Total width (mm) | 2322 |
| Total height (mm) | 2880 |
| Interior width (mm) | 2174 |
| Standing height (mm) | 1975 |
| Front side seating group (mm) | 1000 |
| Bed conversion of the seating group (mm)( 3 ) | 2000 x 1000 |
| Rear bed (mm) | 2 x 2030 x 830 |
| Coachbuild bed / Lift-up bed (mm) | 1930 x 1500 |
| Extension to X sleeping areas | 6 |
| Permissible number of people with 3-point seatbelts total* | 4 |
| Seat extension to X persons( 4 ) | 4 |
| Wall thickness of wall (mm) | 30 |
| Wall thickness of roof (mm) | 30 |
| Wall thickness of floor (mm) | 38 |
| Fresh water tank (l)( 5 ) | 138 ltr. |
| Battery capacity (Ah) | 1 x 80 Ah Gel |
| Water volume in drive position (l) | 100 ltr. |
(1)Dimensions in ready-to-drive state as per EU Directive 1230/2012: Vehicle with standard features according to the manufacturer specifications, 90% of the fill capacity for fuel, 75 kg (weight of the driver), water in drive position and gas (11 kg gas cylinder made of aluminium), without special features
(2)Note combination weight
(3)Not in conjunction with 6430 table with chrome-plated pedestal or 6470 wardrobe instead of single seat
(4)Activa One: Only with seat belts facing away from the direction of travel and 40 H chassis | Profila T/RS: only in combination with 2324 “total mass to 3.65 t” or 2313 Maxi chassis
(5)Water volume in drive position 25 l. If there is sufficient residual cargo, the water tank with a marked capacity of 25 l can be filled to its actual capacity
Equipment
Engine
| serial/optional | |
|---|---|
| Fiat 180 HP motor (surcharge compared to 140 HP) | optional |
| Fiat 140 HP motor | serial |
Other options
| serial/optional | |
|---|---|
| Fiat automatic transmission | optional |
| Reinforced front axle springs | optional |
| Fuel tank, 90 litre | optional |
| Heavy Duty | optional |
Total mass
| serial/optional | |
|---|---|
| Maxi chassis 4.25t | optional |
| Maxi chassis 4.4t | optional |
| Increase of total mass to 3.65t | optional |
| Reduction of total mass to 3.5 t | optional |
Exterior
| serial/optional | |
|---|---|
| Spare wheel | optional |
| Superstructure door with central locking | optional |
| Windscreen wiper system with winter parking position | optional |
| Rear design package | optional |
| Insulating double glazing | optional |
| Rear comfort supports | optional |
| Trailer coupling | optional |
| Roof-mounted air-conditioning system 230 Volt | optional |
| Roof-mounted air-conditioning system 230 Volt (surch. Mond.) | optional |
| External shower (cold/warm) | optional |
| Window in toilet room | optional |
| Electric roof fan | optional |
| Tilting roof hood (Heki) | optional |
| Garage door service flap | serial |
Equipment packages
| serial/optional | |
|---|---|
| Exclusive design package | optional |
| Mondial package Integra Line (moniceiver (Xzent) with rear-view camera, steering wheel controls, electric parking brake, tilting roof hood (Heki), superstructure door with central locking, electric roof fan, mesh screen for cabin door, pre-cabling for solar power system) | optional |
| Mondial-Plus-Package Integra Line w/o automatic transmission (naviceiver with twin eye rear-view camera, 90 litre fuel tank, 16 aluminium rims, carpet in the driver’s cab, 180HP HD motor, Heavy Duty, maxi chassis 4.4t, automatic air conditioning, leather steering wheel and gearshift knob, inductive charging station, multi-function socket, external shower (hot/cold), external gas socket, heat exchanger, windscreen wiper system with winter parking position, insulating double glazing, electric front pleading, Lithium battery (1x)) | optional |
Multimedia
| serial/optional | |
|---|---|
| Loudspeakers (2) in superstr. | optional |
| Flat screen wall bracket in front area | optional |
Interior
| serial/optional | |
|---|---|
| Comfort seat | optional |
| Driver cab floor insulating mat | optional |
| Driver cab floor heating (heated floor mat / Alde heating) | optional |
| Driver's cab dimming system | serial |
| Electric front pleading | optional |
| Mesh screen for cabin door | optional |
| Driver cab seats in superstructure upholstery | serial |
| Additional bed for 2 people (conversion of seating group) | optional |
| Electrically adjustable lift-up bed | optional |
| Manually adjustable lift-up bed | serial |
| Carpeted floor in superstructure | optional |
| Storage cabinets instead of lift-up bed | optional |
| Background lighting | serial |
Additional optional extras
| serial/optional | |
|---|---|
| EB bedspread | optional |
| Maka décor | serial |
| Lasca décor | optional |
| Rana décor | optional |
Bicycle carrier
| serial/optional | |
|---|---|
| Bike carrier extension kit 4-way | optional |
| Bike carrier for 2 bikes | optional |
| Lowerable E-bikes carrier | optional |
Sunblinds
| serial/optional | |
|---|---|
| 5 m canopy | optional |
Technical services
| serial/optional | |
|---|---|
| Multi-function socket | optional |
| Heat exchanger | optional |
| Lithium battery (1x) | optional |
| Lithium batteries (2x) | optional |
| 2nd gel battery - 80 Ah | optional |
| Pre-cabling for solar power system | optional |
| External gas socket | optional |
| Duo Control CS with ice-ex | optional |
| Waste water tank, insulated and heated | serial |
Fabrics
| serial/optional | |
|---|---|
| Milano upholstery fabric | optional |
| Dara upholstery fabric | optional |
| Pisa upholstery fabric | optional |
| Como upholstery fabric | serial |
Furniture
| serial/optional | |
|---|---|
| Chalet furniture décor | serial |
Heating
| serial/optional | |
|---|---|
| Hot water heating - Alde | serial |
Kitchen
| serial/optional | |
|---|---|
| Extractor hood | optional |
| Oven | optional |
| Large refrigerator | serial |
Versicherungsprodukte
| serial/optional | |
|---|---|
| 1 year follow-on guarantee < 4.5t | optional |
| 2 year follow-on guarantee < 4.5t | optional |
| 3 year follow-on guarantee < 4.5t | optional |
Additional products
| serial/optional | |
|---|---|
| Reduction of travel seats by 1 | optional |
| Reduct. of travel seats by 2 | optional |
| Reduction of travel seats by 3 | optional |
| Reduction of travel seats by 4 | optional |
